ASTM A216WCB Material Swing Check Valve, DN300, PN25, DIN 3356, RF Flanged End

Detailed Product Description Type: Swing Check Valve Body Materials: ASTM A216 WCB Trim Materials: 13% CR Class Rating: PN16 Size: 12 Inch (DN300) Connection Ends: Flanged RF
Model Number:
CX-SWCK-21
Minimum Order Quantity:
1PC
Prices:
Negotiable
Packaging Details:
Plywood Case
Delivery Time:
30~60 work days
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
1000pcs per month
Place of Origin:
WENZHOU,CHINA
Certification:
API,ISO,CE

Detailed Product Description

Type: Swing Check Valve Body Materials: ASTM A216 WCB
Trim Materials: 13% CR Class Rating: PN16
Size: 12 Inch (DN300) Connection Ends: Flanged RF

ASTM A216WCB Material Swing Check Valve, DN300, PN25, DIN 3356, RF Flanged End

Name: Swing type check valve.
Design: DIN 3356.
Body: ASTM A216WCB.
Nominal size: DN300.
Nominal class: PN25.
Connection ends: RF flanged ends.
Face to face: EN558-1/line 48(DIN 3202 F6).
Test and inspection: EN12266-1.

Check valves are automatically actuated.they are opened and sustained in the open position by the force of velocity pressure, and closed by the force of gravity. Seating load and resultant tightness is dependent upon back pressure. The disc and associated moving parts may be in a constant state of movement if the velocity pressure is not sufficient to hold the valve in a wide open and stable position.   Cast steel swing check valves can be furnished with outside lever and adjustable weight when so ordered. With the lever and weight mounted so that the weight assistes the disc in closing, the valve closes more rapidly when flow stops, thus minimizing reversal of flow and resultant surge and shock. With the lever and weight mounted to balance the weight of the disc, the valve becomes more sensitive to low inlet velocities.   Swing check valvs are used to prevent reversal of flow in horizontal or vertical pipe lines. in Vertical lines, or for any angle from hirzontal to vertical , they can be used for upward flow only.

General Design Features

  • Valve Range: Size 2-36Inch (DN50-DN900), Rating Class 150-1500Lb (PN16-PN250)
  • Valve Applications: Oil Industry, Chemical, Power Station, Refinery, Water Treatment, etc...
  • Design Standard: BS1868, AP6D, ASME B16.34, API 594, etc...
  • Face-to-Face Standard: ASME B16.10, API6D, etc...
  • Connection Standard: Flange per ASME B16.5/ASME B16.47(NPS≥26”), BW per ASME B16.25, SW per ASME B16.11, NPT per ASME B1.20.1, etc...
  • Testing Standard: API 598
  • Type of Bore: Full Bore, etc...
  • Valve Material: Cast Steel
  • Connection Type: FF, RF, RTJ, BW
  • Disc Type: Swing Type
  • Seat Type: Welded Seat, Threaded Seat, Integral Seat, etc...
  • Body-Bonnet Connection Type: Bolted Bonnet, etc...
  • Other Features: Hard Facing, Bypass Arrangement, Drain and Vent Connection, Outside Dashpot Design, etc...


Main Material Applied for Swing Check Valve

MAIN MATERIAL LIST
Body/Bonnet: A216-WCB/WCC,A352-LCB/LCC,A217-WC6/WC9/C5/C12,A351-CF8/CF8M/CF3/CF3M/CF8C/CN7M,A890 4A/5A/6A
Disc A216-WCB/WCC,A352-LCB/LCC,A217-WC6/WC9/C5/C12,A351-CF8/CF8M/CF3/CF3M/CF8C/CN7M,A890 4A/5A/6A,A217-CA15,Other
Pin F6a,SS304,SS304L,SS316,SS316L,SS321,ALLOY-20,SS17-4PH,F51,F53,F55,Other
Seat Ring A105,LF2,F11,F22,F5,F9,F6a,SS304,SS304L,SS316,SS316L,SS321,ALLOY-20,F51,F53,F55Other
Seal Surface 13CR/13CR,13CR/STL,STL/STL,SS304/SS304,SS316/SS316,SS316/STL,ALLOY-20/ALLOY-20,F51/F51,Other
Gasket SS304+Graphite, SS316+Graphite,SS316L+Graphite,1008,SS304L,SS316L, Other
Packing Flexible Graphite, Other
Bolts/Nuts A193 Gr.B7(M)/A194 Gr.2H(M), A320 Gr.L7(M)/ A194 Gr.7(M) or Gr.4(M), A193 Gr.B16/ A194 Gr.7,A193 Gr.B8/ A194 Gr.8,
A193 Gr.B8M/A194 Gr.8M,A453 Gr.660,etc
Note *For More Detailed of our products,pls kindly let us know freely.

We also spercial produce of Flange Ball Valve, Gate Valve, Globe Valve, Check Valve, Butterfly Valve & Y Strainer.Any inquiry for these valves,pls let us know freely by sales@cncxvalve.com

We will give you best price immediately,and meanwhile,we will supply better service with your other suppliers.Why not have a try.

Competitive Advantages:

1. Our products is guaranteed within 18 months after delivery.
2. We offer free sample if interest before orders(Customers pay sample fee and courier fee first, we will deduct the sample fee from the payment when the order is officially signed).
3. Technology renovation, process improvement, structure optimization and quality improvement.
4. Excellent after-sales service system, providing timely and optimal service, which help you to win the market.
5. Convenient shipping sea port, and standard exporting packing of plywood case.
6. 100% inspection & testing before delivery.
7. Third party inspection on customer requirement.
