Swing type forged Steel Check Valve Bolted bonnet,a182 f316l body,npt threaded,1inch,800lb
Detailed Product Description
Type:
Swing Check Valve
Material:
ASTM A182 Gr. F316L
Trim:
10
Size:
1inch(DN25)
Ends:
SW,BW,NPT Threaded,Flanged
Pressure:
ANSI 800LB
Surface Tr
- Model Number:
- CX-FCK-10
- Minimum Order Quantity:
- 1PC
- Prices:
- Negotiable
- Packaging Details:
- Plywood Case
- Delivery Time:
- 7-30 work days
- Payment Terms:
- L/C, D/A, D/P, T/T, Western Union, MoneyGram
- Supply Ability:
- 10,000pcs per month
- Place of Origin:
- WENZHOU,CHINA
- Certification:
- API,ISO,CE
Detailed Product Description
| Type: | Swing Check Valve | Material: | ASTM A182 Gr. F316L |
|---|---|---|---|
| Trim: | 10 | Size: | 1inch(DN25) |
| Ends: | SW,BW,NPT Threaded,Flanged | Pressure: | ANSI 800LB |
| Surface Treatment: | No | ||
| High Light: | pressure seal check valve , vertical lift check valve | ||
Swing type forged Steel Check Valve Bolted bonnet,a182 f316l body,npt threaded,1inch,800lb
1:General Design Features
- Valve Range: Size 1/2-2Inch (DN15-DN50), Rating Class 150-2500Lb (PN16-PN420)
- Valve Applications: Oil Industry, Chemical, Power Station, Refinery, Water Treatment, etc...
- Design Standard: API602, BS5352, ASME B16.34, etc...
- Face-to-Face Standard: ASME B16.10, Manufacturer’s STD, etc...
- Connection Standard: Flange per ASME B16.5/ASME B16.47(NPS≥26”), BW per ASME B16.25, SW per ASME B16.11, NPT per ASME B1.20.1, Other
- Testing Standard: API 598
- Type of Bore: Full Bore, Reduced Bore, etc...
- Valve Material: Cast Steel, Forged Steel
- Connection Type: FF, RF, RTJ, BW, SW, NPT,
- Disc Type: Swing Type, Ball Type, etc...
- Seat Type: Expanded Seat, Integral Seat, etc...
- Body-Bonnet Connection Type: Bolted Bonnet, Welded Bonnet, Pressure Sealed Bonnet, etc...
- Other Features: Hard Facing, Bypass Arrangement, Drain and Vent Connection, Outside Dashpot Design, etc...
2:Main Material Applied for Forged Steel Check Valve
| MAIN MATERIAL LIST | |
| Body/Bonnet: | A105,A182-LF2,A182-F11/F22/F5/F9,A182-F304/F304L/F316/F316L/F321,ALLOY-20,F51/F53/F55,etc.. |
| Disc | A182-F6a,SS304,SS304L,SS316,SS316L,SS321,ALLOY-20,F51,F53,F55,etc... |
| Pin | F6a,SS304,SS304L,SS316,SS316L,SS321,ALLOY-20,SS17-4PH,F51,F53,F55,etc |
| Seat Ring | F6a,SS304,SS304L,SS316,SS316L,SS321,ALLOY-20,F51,F53,F55,etc... |
| Seal Surface | 13CR/13CR,13CR/STL,STL/STL,SS304/SS304,SS316/SS316,SS316/STL,ALLOY-20/ALLOY-20,F51/F51,etc... |
| Gasket | SS304+Graphite, SS316+Graphite,SS316L+Graphite,1008,SS304L,SS316L, etc |
| Packing | Flexible Graphite, etc... |
| Bolts/Nuts | A193 Gr.B7(M)/A194 Gr.2H(M), A320 Gr.L7(M)/ A194 Gr.7(M) or Gr.4(M), A193 Gr.B16/ A194 Gr.7,A193 Gr.B8/ A194 Gr.8, A193 Gr.B8M/A194 Gr.8M,A453 Gr.660,etc |
| Note | *For More information of our forged valves,pls kindly contact with us Via email: sales@cncxvalve.com |
We also spercial produce of Flange Ball Valve, Gate Valve, Globe Valve, Check Valve, Butterfly Valve & Y Strainer.Any inquiry for these valves,pls let us know freely by sales@cncxvalve.com
We will give you best price immediately,and meanwhile,we will supply better service with your other suppliers.Why not have a try.
